The FRD003 Sidewall Fire Sprinkler is designed for lateral installation where ceiling-mounted units are impractical. Ideal for hallways, rooms, and tight ceiling spaces, it offers efficient coverage with a K-factor of 5.6 and thermally responsive bulbs. Available in both standard and quick response models, each variant supports specific temperature ratings, ensuring performance tailored to building requirements.
Space-saving sidewall sprinkler with temp-rated quick or standard response.
• K Factor: K 5.6 @ US (80@Metric)
• Thread Size: DN15 (1/2")
• Connecting Thread: BSP (NPT Optional)
• Main Material: Brass
• Sensitive Element: YF Brand Glass Bulb (JOB Glass Bulb Optional)
• Seal Material: NBR (Teflon Optional)
• Surface Finishing: Chrome (Natural Brass Optional)
• Thread Size: 1/2” (DN15)
• K-Factor: 5.6
• Response Type: Standard & Quick
• Temperature Ratings: 57°C, 68°C, 79°C, 93°C, 141°C
• Bulb Sizes: Ø5mm (Standard), Ø3mm (Quick)
• Bulb Colors: Orange, Red, Yellow, Green, Blue
