The PS30-50T fire water monitor delivers powerful, targeted water streams with a flow capacity suited for medium to large-scale firefighting operations. Its robust manual swivel and elevation controls allow precise stream direction, while corrosion-resistant materials ensure long-term reliability in harsh environments. Commonly installed in refineries, tank farms, and chemical plants, it provides critical first-response capability with minimal maintenance.
A manually operated fire water monitor designed for high-capacity water flow and directional control—ideal for fixed firefighting installations and industrial fire protection systems.
• Aluminum alloy construction, hard coated anodized
• Flow Rate: Stack tip adjustable 30 - 50 LPS
• Jetting Pattern: Straight stream
• 360° rotation horizontally
• -45° to +85° elevate vertically
• Flange standard: BS4504, ANSI150, GB etc.
• Flow Rate: 1800 LPM up to 3000 LPM
• Max. Reach @ 10 bar: 65 meters @ 3000 LPM
• Max Range of Monitor: -45° to +75° Vertically, 360° Rotation
• Monitor Inlet: Flange 4" BS4504 is standard, other standard flange is available.
• Material: Monitor & Nozzle - Hard coated anodized aluminum alloy. Triller - SS304 Stainless steel
